DESCRIPTION

Basic Info.

Type	Airflow Spray
Certification	ISO/CE
Heating Source	Electricity/LPG/Natural Gas/Oil/Steam
Rotary Speed	15000-25000
After Service	Video Support,Online Support, Spare Parts
Material	SUS304, SUS304L, SUS316, SUS316L
Product Name	LPG Spray Dryer
Core Components	Bearing,Pump,Gear,Motor,Engine
Voltage	220V-480V
Transport Package	Wooden Cases
Specification	Deponds On The Model
Trademark	TAYACN
Origin	China
HS Code	8419399090
Production Capacity	5sets/Year

Product Description

LPG Spray Dryer Description
LPG Spray dryer is a wide applied process in the liquid process shaping and drying industry. Particularly it is suitable for producing powder, granule or block solid product from solution, emulsion, suspending liquid, and pumped paste liquid. Therefore when the distribution of granule size, final moisture, bulk density, granule shape of finished product must be conformed to accuracy standard, the spray drying is an ideal process.
LPG Spray Dryer Application
It's widely used in foodstuff, pharmaceutical and chemical industries, such as food flavor, egg powder, amino acid product, magnesium citrate, tea, herbal extract, beef powder, protein, maltodextrin, blood, starch, food ingredients, yeast, collagen, whey, Mg citrate, humic acid, ceramic powder, vitamin, urea resin, pectin, stevia, spirulina, microalgae, gum arabic, pigment, PAC, zinc sulfate, organic magnesium compounds, vegetable juice, coffee, creamer, coconut milk, gelatin etc.
Working Principle of LPG Spray Dryer
After filtering and heating, the hot fresh air enters into the air distributor at the top of the drying chamber, distributed in spiral way uniformly from up to down. At the same time, the feeding liquid is pumped to the top atomizer, then be sprayed to an extremely fine mist liquid drop. Through the short time of direct contact with hot air, the moisture evaporated at once, the solid remains to be powder. The dry powder will be discharged continuously from the bottom of the drying tower and cyclone collector, the exhaust air will be discharged after cleaning.
(1) Start-stop of the dryer is quite simple
(2) After material feeding is stopped, they can be easily discharged out of the dryer by harrows.
(3) Careful cleaning and observation can be carried inside the equipment through the large-scale viewing window.

Model	Food / Industrial Spray Dryer MODEL LPG-
	5	25	50	100	150	200-5000
Inlet air temperature	≤ 350°C
Outlet air temperature	80-90°C
Evaporate capacity (kg/h)	5	25	50	100	150	200-5000
Atomizer type	compressed air drive	mechanical drive
Rotary speed	25000	22000	21500	18000	18000	15000
Diameter of atomizer disc (mm)	50	120	120	120	150	180-500
Heating source	Electricity	Electricity/LPG/	Electricity/LPG/	Electricity/LPG/	Electricity/LPG/	Electricity/LPG/
		Natural gas/Oil/Steam	Natural gas/Oil/Steam	Natural gas/Oil/Steam	Natural gas/Oil/Steam	Natural gas/Oil/Steam
Electric-heating power (kw)	9	-	-	-	-	-
Dry powder yield (%)	≥ 95	≥ 95	≥ 95	≥ 95	≥ 95	≥ 95
